The use of DC motor Drive and matters needing attention

Dc motor Drive parameters:

1. Input voltage: AC220V.

2, output voltage: DC0-90V, 0-110V, 0-160V, 0-180V, 0-220V.

3, output current: DC: 4A6A8A10A15A20A.

4, rated excitation voltage/current: 110V220V (DC) /3A.

5: Given signal: 0~5V (DC) standard signal (such as: PLC signal control or MCU signal control) or 10K/2W potentiometer.

Dc motor Drive features:

1, speed regulation ratio 1:100 (open loop) output voltage (0- rating)

2. High starting torque at low speed.

3, PWM pulse width modulation technology, low noise.

4, double closed loop PI adjustment.

5, current setting, current limiting protection, overcurrent alarm function.

6. Latching control function

7, soft start soft stop time setting function.

8, the upper limit speed setting function.

9. Good following and fast response.

10. Standard signal interface (suitable for various DA signals, 0-5V or 0-10V).

Use of DC motor Drive:

1. Place the DC Drive case in a place with good ventilation and no corrosive gas. Check whether the internal screws are loose due to transportation.

2. Connect the AC power line and connect the excitation voltage according to positive and negative, otherwise it will cause reversal.

3. At the output end of the main armature circuit, the + pole is connected to the positive pole of the main armature of the DC motor, and the - pole is connected to the negative pole of the main armature.

4, speed feedback + pole connected to the speed measuring generator feedback signal positive pole, speed feedback - pole connected to the speed measuring generator feedback signal negative pole.

5, before operation, manually adjust the potentiometer on the panel to zero. Then send the power supply voltage, and then rotate the manual adjustment potentiometer knob, you can start the armature motor work output up to 200V.

Dc motor Drive note:

1, DC Drive application environment, should be no dust, low humidity, good ventilation environment.

2. Check the operation of the controller regularly and clean the dust on the radiator. Ensure that the heat dissipation of the module is good.
